It was summer time. I was enjoying my time. Little did i know that my tough days were coming. Yes that’s right. I had been assigned the work on printing. I wouldn’t say it was very difficult. Its just that i had no idea how printing works in WPF world and to my surprise it wasn’t as easy as few Google searches. So after struggling a lot and spending some extra time apart from normal hours, i ended up with some pretty good experience that i want to share with you all.
Overview
In an attempt to explain things i split it into 5 sections as follows :
- Demonstration : Overview of how it works
- Usage : Code samples
- DocumentPaginator : How the pagination is achieved
- PrinterUtility : Retrieval of available printers and their properties / preferences
Demonstration
WPF print engine comes with the following features at the moment :
- Smart print preview to see what it would look like on after printing on the printer and paper you selected
- Support for changing printer preferences directly
- Scale page content in the print preview to fit in less pages
- Turn on/off page numbers
- Asynchronous printing directly to printer
- Any WPF Visual Support
- Any WPF FrameworkElement Support
- DataTable Support
The above snapshot shows the demo application. As you can see it has as this stage, support for generating print preview for WPF Visual or a DataTable as input. Below is a snapshot of what we get then select “Print This Visual”. You can see that the visual is split in 2 separate pages because the current selected paper (A4) is smaller than the visual’s size.
You can change the printer, the printer preferences, the number of copies to print from the printing options tool. It also allows you to print the page numbers on each page or hide them.
There is one neat feature – “Print Size” that allows you to shrink the generated print preview content’s size to your will, so that you can fit it in less number of pages. This is done with the help of a slider giving you complete control over the resize ratio so that you can decide when you data is not being too small. This is unique in the sense that many applications allow you to shrink but not all allow you to control how much.
Notice below the updated snapshot after it has been shrunken just enough to fit into 1 pages instead of 2.
Similarly the demo application show an example for using DataTable as input for the print preview. Notice that the pagination is done such that no columns or row get cut and yet the maximum possible row or column is fit in the selected paper size.
Usage
Printing a WPF Visual:
First you need to create an instance of the printcontrol which you can using the PrintControlFactory.Create method. It has few overloads, that i will be adding more to in future. One of those is the one that takes a size and a visual as input. Visual is the WPF visual (could be any control, panel, grid, window) anything that you want to print. When you specify a visual, all its children, as rendered on the screen are taken into consideration.
var visualSize = new Size(visual.ActualWidth, visual.ActualHeight);
var printControl = PrintControlFactory.Create(visualSize, visual);
printControl.ShowPrintPreview();
Printing a DataTable as source :
In order to give a datatable as a source, you will need to also supply the width of each column as a List<double>. Then instantiate a printcontrol using the PrintControlFactory.Create method that takes a datable and columnsWidths as arguments.
var columnWidths = new List<double>() {30, 40, 300, 300, 150};
var printControl = PrintControlFactory.Create(dataTable, columnWidths, headerTemplate);
printControl.ShowPrintPreview();
Printing a DataTable as source with Header Template :
There is also an overload to give a header template. The header template to supply is a string of the Xaml File you will create. This can be in the form of a user control. To denote the page number and it place holder, simple place the verbatim string
“@PageNumber” in its placeholder.
<UserControl x:Class="DEMOApplication.HeaderTemplate"
xmlns="http://schemas.microsoft.com/winfx/2006/xaml/presentation"
xmlns:x="http://schemas.microsoft.com/winfx/2006/xaml"
xmlns:mc="http://schemas.openxmlformats.org/markup-compatibility/2006"
xmlns:d="http://schemas.microsoft.com/expression/blend/2008"
mc:Ignorable="d" d:DesignWidth="919">
<DockPanel LastChildFill="False" Margin="10">
<Image Source="Images/headerDemo.gif" DockPanel.Dock="Left" Stretch="None" />
<TextBlock DockPanel.Dock="Right" VerticalAlignment="Bottom" FontWeight="Bold" TextWrapping="Wrap" Text="Page Number : @PageNumber"/>
</DockPanel>
</UserControl>
var columnWidths = new List<double>() {30, 40, 300, 300, 150};
var ht = new HeaderTemplate();
var headerTemplate = XamlWriter.Save(ht);
var printControl = PrintControlFactory.Create(dataTable, columnWidths, headerTemplate);
printControl.ShowPrintPreview();
How the control is initiated
At the heart of the
print engine are two parts. One is the
PrintControlFactory that creates a
DrawingVisual object to be used later by the control. I will explain this shortly. The second important part (I should probably mention it first, because this is in fact the most important bit) is, wait for it..., the
Paginator.
The following diagram displays a flowchart of how the whole process works. I will explain one step at a time and give the implementation details.
Step 1: Initialize the Print Engine
The PrintControlFactory.Create() method is responsible for creating an instance of the PrintControl. This method has several overloads for working with a WPF Visual item. Also, there is an overload that takes aDataTable, widths of the columns as List, and a header template as string. We will look into the working of the engine with DataTable much later. Let's first understand the complete flow when using a WPFVisual.
var unityContainer = new UnityContainer();
PrintEngineModule.Initialize(unityContainer);
var printControlPresenter = (PrintControlViewModel)unityContainer.ResolvePrintControlViewModel>();
You will notice the above part of code in the create method. This is where the print engine is assigned a new instance of UnityContainer since I am using Prism and Unity for MVVM architecture. Here I register all the Views and ViewModels to the container.
Step 2: Build Graph Visual
public static DrawingVisual BuildGraphVisual(PageMediaSize pageSize, Visual visual)
{
var drawingVisual = new DrawingVisual();
using (var drawingContext = drawingVisual.RenderOpen())
{
var visualContent = visual;
var rect = new Rect
{
X = 0,
Y = 0,
Width = pageSize.Width.Value,
Height = pageSize.Height.Value
};
var stretch = Stretch.None;
var visualBrush = new VisualBrush(visualContent) { Stretch = stretch };
drawingContext.DrawRectangle(visualBrush, null, rect);
drawingContext.PushOpacityMask(Brushes.White);
}
return drawingVisual;
}
This method takes a
WPF Visual and creates a
DrawingVisual object. Why we need this is very crucial. If you have already run the sample application in the source code and played with it, you will notice that based on the selected
printer and paper type, the visual is paginated into multiple pages. This is possible due to the fact that we can clip a certain area of the original
DrawingVisual starting from any X,Y co-ordinate. I will show this further below.
In order to create this
DrawingVisual, I have created a
VisualBrush with the given input and painted with it.
Step 3: Initialize Printer Properties
This is another interesting area of the engine and in fact was a little challenge for me at the beginning. This is the part where I connect to the installed printers to fetch their properties such as the PaperSizes, DefaultPaper,printer hardware margin, etc. Also I have made sure that I do these once during the life time because this operation is expensive and sometimes takes long depending on the type of printers you have. The class PrintUtlity deals with all these operations. One such method that gets the list of installed printers is shown below. I have used Enterprise Library for caching these values so that these expensive operations are done only once.
public PrintQueueCollection GetPrinters()
{
if (!_cacheHelper.Contains("Printers"))
{
var printServer = new PrintServer();
_cacheHelper.Add("Printers", printServer.GetPrintQueues(
new[]
{
EnumeratedPrintQueueTypes.Connections,
EnumeratedPrintQueueTypes.Local
}));
}
var printers = (PrintQueueCollection)_cacheHelper.GetData("Printers");
return printers;
}
Step 4: Create Scaled Visual
The method ReloadPreview() executes when the control is first loaded. In fact from this step to the last step, everything takes place in the ReloadPreview method.
private DrawingVisual GetScaledVisual(double scale)
{
if (scale == 1)
return DrawingVisual;
var visual = new DrawingVisual();
using (var dc = visual.RenderOpen())
{
dc.PushTransform(new ScaleTransform(scale, scale));
dc.DrawDrawing(DrawingVisual.Drawing);
} return visual;
}
This step would make no sense at first, but when you use the option to scale the visual so that it takes up less space, the scale value changes ranging from 0 to 1 where 1 is 100% size and 0% the original size. This is done by performing a ScaleTransform on the DrawingVisual.
Step 5: Setup Paginator
Ahh... the most interesting and intelligent class of the whole system. The
Paginator! Rhymes pretty well will
Arnold Schwarzenegger. This class does all the heavy lifting of cutting the entire visual into separate individual pages.
There are several Paginators in the project. Each able to work with one kind of pagination.
VisualPaginator: This has two roles. First, it contains all the common logic for all the paginators and also is a base class to the other paginators. Second, it is responsible for performing page calculation and clipping of a given visual into separate individual pages. DataTablePaginator: This does the pagination when a DataTable is used as the source for the printpreview. DataGridPaginator: This does the pagination when a WPF DataGrid control is given as the input. This feature is still not complete because I am trying to add this feature to work even when the DataGrid is in Virtualization mode.
public VisualPaginator(DrawingVisual source, Size printSize, Thickness pageMargins, Thickness originalMargin)
{
DrawingVisual = source;
_printSize = printSize;
PageMargins = pageMargins;
_originalMargin = originalMargin;
}
I will describe the details of all the paginators in part II of the series as well as complete the DataGridPaginatorand its usage sample. In this part, we will only look into the details with respect to the VisualPaginator. The constructor as you can see is pretty straightforward. Next comes the Initialize() method. It performs two important pieces of work:
1: Calculates the Printable Page Width and Height
This calculation is necessary because different printers have different hardware margins. So if we draw anything outside the bounds of this margin, that part will get cut. So when calculating the number of pages required, this hardware margin has to be kept under consideration.
var totalHorizontalMargin = PageMargins.Left + PageMargins.Right;
var toltalVerticalMargin = PageMargins.Top + PageMargins.Bottom;
PrintablePageWidth = PageSize.Width - totalHorizontalMargin;
PrintablePageHeight = PageSize.Height - toltalVerticalMargin
2: Calculates the Horizontal and Vertical Page Count
This is fairly straightforward in the case of VisualPaginator. Other paginators, specially the ItemsPaginatordoes the most complex calculation. In fact, calculating the page count is what separates the different paginators. If you want to add support for your own control type, let's say a third part datagrid like xCeed grid control, then all you do is create a new paginator inheriting from VisualPaginator and write your own logic for the horizontal and vertical page count. OK, let's gets back to our VisualPaginator. Here the horizontal page count is the total visual width divided by the printable width of each page. Similarly, the vertical page count is the total height of the visual divided by the height of each individual page.
Step 6: Create Pages
Here I do an iteration to walk through the whole
DrawingVisual and save each block as a separate page. This is done by first looping from 0 to the number of horizontal pages (calculated in the previous step) and then moving to the next row and repeating until I cover the total horizontal page count. All these sepsrate pages are saved in a collection,
DrawingVisuals, to be later used during
printing or showing the preview.
private void CreateAllPageVisuals()
{
DrawingVisuals = new List();
for (var verticalPageNumber = 0; verticalPageNumber < _verticalPageCount; verticalPageNumber++)
{
for (var horizontalPageNumber = 0; horizontalPageNumber < HorizontalPageCount; horizontalPageNumber++)
{
const float horizontalOffset = 0;
var verticalOffset = (float)(verticalPageNumber * PrintablePageHeight);
var pageBounds = GetPageBounds(horizontalPageNumber,
verticalPageNumber, horizontalOffset, verticalOffset);
var visual = new DrawingVisual();
using (var dc = visual.RenderOpen())
{
CreatePageVisual(pageBounds, DrawingVisual, IsFooterPage(horizontalPageNumber), dc);
}
DrawingVisuals.Add(visual);
}
}
}
Step 7: Show Preview
After the pages are calculated, we are ready to show them to the user as preview. Since I am using a standard mechanism for the pagination and using a custom implementation of the .NET Framework's
DocumentPaginatorclass, it should be fairly straightforward to simply give the paginator to the
DocumentViewer. But there is a catch. When the number of pages increase, specially in the area of several hundreds, the standard
DocumentViewer starts behaving awkward and even fails to display all the pages sometimes. So instead I went for a rather custom, but simple solution.
Using the collection of drawing visuals created by the paginator, I create a simple WPF Visual object from each of these DrawingVisuals and display them in a StackPanel. The code is rather self explanatory.
private Border GetPageUiElement(int i, DocumentPaginator paginator, double scale)
{
var source = paginator.GetPage(i);
var border = new Border()
{
Background = Brushes.White
};
border.Margin = new Thickness(10 * scale);
border.BorderBrush = Brushes.DarkGray;
border.BorderThickness = new Thickness(1);
var margin = new Thickness();
var rectangle = new Rectangle();
rectangle.Width = ((source.Size.Width * 0.96 - (margin.Left + margin.Right)) * scale);
rectangle.Height = ((source.Size.Height * 0.96 - (margin.Top + margin.Bottom)) * scale);
rectangle.Margin = new Thickness(margin.Left * scale, margin.Top * scale, margin.Right * scale, margin.Bottom * scale);
rectangle.Fill = Brushes.White;
var vb = new VisualBrush(source.Visual);
vb.Opacity = 1;
vb.Stretch = Stretch.Uniform;
rectangle.Fill = vb;
border.Child = rectangle;
return border;
}
Step 8: Change Paper / Printer Options
This is the step where the user selects a different paper size, page orientation, etc. Steps 4 to 7 are performed again to calculate new pages and display them.
More Info
This is the just the introduction, to both the project and its documentation. At this moment i believe there are many areas that can be improved, including facility for the WPF DataGrid as input, support for footer template, refactoring the codebase more, better samples to name a few. I would love to welcome anyone interested in contributing to the source code and bring in better improvements and features.
Also i have plan to give Visual Studio design time support for creating printing templates.
